2014 August 1: Prices exclude Freight and GST. Subject to change without notice
450
Site Cleaning
Accessories
R&M Nr Size Psi
Length(1)
Width (2)
706 03 1/4” 500 bar
69 mm
26 mm
706 10 3/8” 500 bar
72 mm
32 mm
706 15 1/2” 500 bar
83 mm
35 mm
706 18 3/4” 315 bar
95 mm
49 mm
R&M Nr
Size Psi
Length
706 23
1/4” 315 bar
69 mm
706 24
38” 315 bar
72 mm
706 25
1/2” 315 bar
83 mm
706 27
3/4” 315 bar
95 mm
Width
48 mm
52 mm
59 mm
72 mm
R&M Nr
Size Psi
Length
707 15
1/4” 500 bar
69 mm
707 25
3/8” 500 bar
72 mm
707 35
1/2” 500 bar
83 mm
707 45
3/4” 315 bar
95 mm
Width
26 mm
32 mm
35 mm
49 mm
R&M Nr Psi
706 05 500 bar M22 M
M22 F
706 151 500 bar M22 M Pipe diameter 16
706 20 500 bar M18 M
M18 M
706 031 500 bar M22 F
M22 F
706 101 500 bar M22 M
M22 M
Length
65 mm
83 mm
64 mm
110 mm
100 mm
R&M Nr
Material
708 00
Stainless steel
R&M Nr
Thread
Length
Width
707 10
1/4”
52 mm
28 mm
707 20
3/8”
52 mm
28 mm
707 30
1/2”
64 mm
31 mm
707 40
3/4”
71 mm
35 mm
R&M Nr
Length
107 008 09
6m
R&M Nr
107 208 09
R&M Nr
107 608 09
R&M Nr
107 408 09
R&M Nr
107 308 069
R&M Nr
107 308 09
R&M Nr
107 708 09
R&M Nr
TYP
107 808 19 1
Angle
107 808 29 2
Bracket
High Pressure Ball Valves
Standard
Three way
Standard stainless steel
Valves with connections
U-rails
Connecting rails
Ceiling support brackets
Bumpers
Attachment trolleys
Hose reel trolleys
Hose end clamps
Adjustable bracket in height +
double wall angle
Zinc-plated steel. Ball chrome-plated.
Max. 80°C
Zinc-plated steel. Ball chrome-plated. L-form.
Max. 80°C
Stainless steel V4A / AISI 316 Ti. Ball stainless
steel. Max 100° C
Zinc-plated steel. Ball chrome-plated.
Max. 80°C
Mount for 500 bar ball valves 3/8” + 1/2”
Stainless steel V2A / AISI 304. Ball stainless
steel. Max. 140 bar / 60°C
Hose guide system .stainless steel V2A / AISI 304 . 30 mm profile
Wall Mounts
High Pressure Ball Valves
Further ball valve models are available on request
