Site Cleaning
Accessories
R&M Nr. Pipe Diameter Thread
Typ
592 101 4 10mm
1/4”
L
592 101 2 10mm
1/2”
L
592 13
12mm
3/8”
L
592 12
12mm
3/8”
S
592 14
12mm
M16
L
592 121 12mm
M18
S
592 15
15mm
3/8”
L
592 17
15mm
1/2”
L
592 19
15mm
M18
L
592 16
16mm
1/2”
S
592 161 16mm
M22
S
592 18
18mm
1/2”
L
592 191 18mm
M22
L
592 20
20mm
3/4”
S
592 201 20mm
M27
S
592 201 2 20mm
1/2”
S
592 223 4 22mm
3/4”
L
592 221 22mm
M26
L
Length
39mm
45mm
41mm
41mm
41mm
44mm
45mm
46mm
43mm
50mm
52mm
47mm
46mm
56mm
56mm
31mm
52mm
51mm
R&M Nr Pipe Diameter Thread TYP
596 101 4 10mm
1/4”
L
596 121 4 12mm
1/4”
L
591 10
12mm
1/4”
S
591 12
12mm
3/8”
S
591 120 12mm
1/2”
S
596 153 8 15mm
3/8”
L
596 151 2 15mm
1/2”
L
591 14
16mm
3/8”
S
591 16
16mm
1/2”
S
596 181 2 18mm
1/2”
L
596 183 4 18mm
3/4”
L
591 20
20mm
3/4”
S
591 201 2 20mm
1/2”
S
596 223 4 22mm
3/4”
L
596 183 8 18mm
3/8”
L
Length
2mm
39mm
45mm
33mm
34mm
29mm
29mm
30mm
37mm
42mm
31mm
46mm
42mm
42mm
49mm
R&M Nr
Pipe Diameter TYP
Length
593 081
8mm
L
40mm
593 101
10mm
L
40mm
593 121
12mm
L
43mm
593 12
12mm
S
51mm
593 15
15mm
L
50mm
593 16
16mm
S
63mm
593 18
18mm
L
48mm
593 20
20mm
S
66mm
593 22
22mm
L
52mm
593 30
30mm
S
80mm
R&M Nr
Pipe Diameter TYP
Length
595 081
8mm
L
58mm
595 101
10mm
L
60mm
595 121
12mm
L
64mm
595 12
12mm
S
76mm
595 15
15mm
L
76mm
595 16
16mm
S
91mm
595 18
18mm
L
80mm
595 20
20mm
S
96mm
595 22
22mm
L
88mm
595 30
30mm
L
124mm
R&M Nr
Pipe Diameter TYP
List
594 081
8mm
L
594 101
10mm
L
594 121
12mm
L
594 12
12mm
S
594 15
16mm
L
594 16
16mm
S
$134
594 18
18mm
L
594 20
20mm
S
594 22
22mm
L
594 30
30mm
S
R&M Nr Pipe Diameter Pipe Diameter TYP
593 121 0
12mm
10mm
L
593 151 2
15mm
12mm
L
593 161 2
16mm
12mm
S
593 181 2
18mm
12mm
L
593 181 5
18mm
15mm
L
593 201 2
20mm
12mm
S
593 201 6
20mm
16mm
S
593 221 5
22mm
15mm
L
593 221 8
22mm
18mm
L
593 302 0
30mm
20mm
S
Length
43mm
45mm
54mm
46mm
48mm
60mm
63mm
50mm
50mm
74mm
R&M Nr
Thread
590 081
M14 x 1,5
590 101
M16 x 1,5
590 121
M18 x 1,5
590 123
M20 x 1,5
590 151
M22 x 1,5
590 163
M24 x 1,5
590 181
M26 x 1,5
590 203
M30 x 2
590 221
M36 x 2
590 303
MM42 x 2
R&M Nr Pipe Diameter TYP
590 082 8mm
L
590 102 10mm
L
590 122 12mm
L
590 122 12mm
S
590 152 15mm
L
590 164 16mm
S
590 182 18mm
L
590 204 20mm
S
590 222 22mm
L
590 304 30mm
S
R&M Nr
953 60
TYP
Nominal Pressure (safety factor 4:1)
LL
100 bar
L (6 - 15)
250 bar
L (18 - 22)
160 bar
L (28 - 42)
100 bar
S (6 - 14)
630 bar
S (16 - 25)
400 bar
S (30 - 38)
250 bar
Compression pipe couplings
Type GAI, cone 24°
Type G, cone 24°
Type GE, cone 24°
Type T, cone 24°
Type W, cone 24°
Type GR, cone 24°
Quick Screws
Bicone ringe
Altemp Q NB 50
Stainless steel V4A 1.4571 / AISI 316 Ti
Stainless steel V41 1.4571 / AISI 316 Ti
Stainless steel V4A 1.4571 / AISI 316 Ti
Stainless steel V4A 1.4571 / AISI 316 Ti
Stainless steel V4A 1.4571 / AISI 316 Ti
Stainless steel V4A / AISI 316 Ti
Which operating pressure?
LL = light series
L = solid series
S = heavy duty series
Other connections available on request.
Stainless steel V4A 1.4571 /
AISI 316 Ti. Quick screws as
per DIN 3870.
Bicone ring as per DIN 3861
Form B
Please follow the assem-
bly instructions DIN 3859
Grease for compression
pipe couplings
Pipe coupling in zinc-plated
steel are available on
request.
