2014 August 1: Prices exclude Freight and GST. Subject to change without notice
448
Site Cleaning
Accessories
R&M Nr
Material
598 002 0
Zinc-plated steel
598 002 09
Stainless steel
Pipe Diameter
10
12
15
16
18
20
22
R&M Nr
598 100 4
598 120 4
598 150 4
598 160 4
598 180 4
598 200 4
598 220 4
R&M Nr
598 100 49
598 120 49
598 150 49
598 160 49
598 180 49
598 200 49
598 220 49
Pipe Diameter
10
12
15
16
18
20
22
R&M Nr
598 100 1
598 120 1
598 150 1
598 160 1
598 180 1
598 200 1
598 220 1
R&M Nr
598 100 19
598 120 19
598 150 19
598 160 19
598 180 19
598 200 19
598 220 19
Pipe
diameter R&M Nr.
Wall
Thickness Psi
Weight
10
599 101 0 1,5mm
297 bar 0,319 kg/m
12
599 121 5 1,5mm
241 bar 0,394 kg/m
15
599 151 5 1,5mm
189 bar 0,507 kg/m
16
599 162 0 2,0mm
252 bar 0,701 kg/m
18
599 182 0 2,0mm
221 bar 0,801 kg/m
20
599 202 0 2,0mm
196 bar 0,901 kg/m
22
599 222 0 2,0mm
177 bar 1,000 kg/m
Pipe Diameter
10
12
15
16
18
20
22
R&M Nr
598 100 2
598 120 2
598 150 2
598 160 2
598 180 2
598 200 2
598 220 2
Pipe Diameter
10
12
15
16
18
20
22
R&M Nr
598 100 3
598 120 3
598 150 3
598 160 3
598 180 3
598 200 3
598 220 3
Pipe
Diameter Parcel service (ca. 2m) Forwarding (ca. 5-7m)
10
1-10 pieces (2-20m)
from 5 pieces (from 30m)
12
1-10 pieces (2-20m)
from 5 pieces (from 30m)
15
1-10 pieces (2-20m)
from 5 pieces (from 30m)
16
1-10 pieces (2-20m)
from 5 pieces (from 30m)
18
1-10 pieces (2-20m)
from 4 pieces (from 24m)
20
1-10 pieces (2-20m)
from 4 pieces (from 24m)
22
1-10 pieces (2-20m)
from 4 pieces (from 24m)
Pipe Diameter
Water flow
10
Up to 600 l/h
12
Up to 900 l/h
15
Up to 1100 l/h
16
Up to 1200 l/h
18
Up to 1500 l/h
20
Up to 2400 l/h
22
Up to 3600 l/h
High pressure pipes and holder
Support pipe holder
Assembly on welding plate
For assembly on support
Zinc-plated
steel
Stainless
steel
Zinc-plated
steel
Stainless
steel
Seamless per metre
Twin assembly
Simple assembly
Holder including bolts, discs and welding plate. Holder including nuts for tracks and bolts with
discs.
Do not hesitate
to ask for
current prices!
Stainless steel V2A / AISI 304 - as per DIN
2391 and 17458/1. Production length 5-7 m.
Price is per metre. Other dimensions available
on request.
Holder including twin bolts and fixing support.
Zinc-plated steel.
Holder including bolts and discs, zinc-plated
steel. Suitable for twin assembly and assembly
on double welding plate.
• In case of 5 rods (30m) or more, the
uncut lengths are sent by freight
forwarding.
• In case of less than 5 rods the des-
patch can only be effected by UPS.
The rods are then cut (max. 2 m)
Please consider this when placing
your order.
Zinc-plated steel
Zinc-plated steel
Which diameter for which water flow?
Despatch for pipes (length 5 - 7m)
