2014 August 1: Prices exclude Freight and GST. Subject to change without notice
442
Typical Z Boom Dual Application
Ceiling Mount Configuration
Wall Mount Configuration
Car Wash
Booms
BOOMS - 360° Double Ceiling Mount Rotating ( Z Style)
Part #
Code
Length
Inlet
Rated Psi
Flow
Temp.
Material
List
165
65.933
Z
1550mm
1/4” Bsp F
3100 Psi 40 l/min. 120°C Stainless
$1,599
147 25.0049
MTM
1550mm
1/4” Bsp F x 1/4” BspM
3100 Psi 40 l/min. 120°C Stainless
$1,370
147 25.0050
MTM
1550mm
1/4” Bsp F x 3/8” BspM
3100 Psi 40 l/min. 120°C Stainless
$1,199
BOOMS - Adjustable Boom ( Z Style)
Part #
Mounting
Length
Inlet
Rated Psi
Flow
Temp.
Material
List
Single Spring
155
0156000310
Nil
1550mm 1/4” Bsp F x 1/4” BspM 3600 Psi (max 4060) 45 l/min. 120°C Stainless
$570
155
0156000310A Ceiling Mount 360°
1550mm 1/4” Bsp F x 1/4” BspM 3600 Psi (max 4060) 45 l/min. 120°C Stainless
$1199
155
0156000310B
Wall Mount 180°
1550mm 1/4” Bsp F x 1/4” BspM 3600 Psi (max 4060) 45 l/min. 120°C Stainless
$1399
155
0156000310C Double Ceiling 360° 1550mm 1/4” Bsp F x 1/4” BspM 3600 Psi (max 4060) 45 l/min. 120°C Stainless
$1,899
Dual Spring
155
0156000320A
Nil
1550mm 1/4” Bsp F x 1/4” BspM 3600 Psi (max 4060) 45 l/min. 120°C Stainless
$659
155
0156000320A Ceiling Mount 360°
1550mm 1/4” Bsp F x 1/4” BspM 3600 Psi (max 4060) 45 l/min. 120°C Stainless
$1279
155
0156000320B
Wall Mount 180°
1550mm 1/4” Bsp F x 1/4” BspM 3600 Psi (max 4060) 45 l/min. 120°C Stainless
$1,549
155
0156000320C Double Ceiling 360° 1550mm 1/4” Bsp F x 1/4” BspM 3600 Psi (max 4060) 45 l/min. 120°C Stainless
$2,499
Nb: C Version is a twin Boom & price includes 2 arms
CATALOGUE SPECIAL
Check out the
155
0156000310A
Italian made, but half the price of the
traditional Z Boom
Convert any Boom to the required specification
Ceiling Mount 360°
A
Wall Mount 180°
B
Double Ceiling Mount 360°
C
Convert from Ceiling
to Wall Mount
Attach a Spot Electric and make a
Truck or Car Wash Kit
155
0102000630 $612
155
0102000640 $559
155
0102000740 $1,099
148
109 721 047 $258
145
28.3045.21 ZP $185
Boom Brackets
Jig Drawings available on request
Performance: 40 l/min., 4060 Psi (5075Psi)
Temperature: 150
°
C
