Hot Water
135
Urano - Our heavy duty, high flow series, fitted with an industrial
1440 rpm electric motor, Interpump Italian plunger pump and
brushed stainless cover
Meg Nozzle
145 16.1315.45 $19
INDUSTRIAL - URANO SERIES
Electric Pressure Cleaners - Hot Water
Urano Series
ACCESSORIES INCLUDED
HOT WATER - INDUSTRIAL “Urano”
Industrial use is defined as one where the machine is to be used
in an industrial application, and on a constant basis
General Fe
atures:
Water temperature up to 90°C and Steam to 140°
The Urano series do not run a computer which means in case
of problems a warning light will appear to show a problem but
you can still use your machine until a technician arrives
Pump
• Interpump Italian Plunger pump
Motor
• Heavy duty 4 pole electric motor (1400 rpm) for extended life
• Power cable 4 metres (no plug fitted)
• Delayed
TOTAL STOP
automatically shuts down the pressure
washer down when the gun is closed, adjustable from 0 to 30
seconds
• Automatic stop if machine left idle for 30 minutes
• Machine Stop in case of micro leakages (hunts 5 times and
then shuts down)
Boiler
• Double Coil (C2) vertical boiler with weldless double coil
• Delayed 3 second start of the burner to reduce smoke
• Flame control device system
• Diesel Fuel Tank for Burner - 24 Litres
Control Panel
• Full function , waterproof display panel
• Temperature adjustment knob
• Low voltage controls
Other
• Strong heavy duty stainless canopy
• Large capacity diesel tank
• High pressure detergent pick up system with regulation
• Water break tank to ensure water intake is kept up to the pump
for higher flow models (reduces possible cavitation). Machine
cuts out when there is no water.
• Water softener device with pump & tank
Standard Options
Lance 120mm (no nozzle)
61022100 $114
Hose 10m R2 5/16”
R2AJ400 10m MF $133
+ Fitting:145 26.0750.40
Options available:
Hose Reel $725
Steam Nozzle c/w Lance
33011100 $119
Sandblasting Lance Foam Lance Rotating Brush Drain Clng Kit 25m Stainless Coil Hose extensions Suction Hose Kit Coil Descaler (10ltr)
Urano 33010772 $399 33010901 $169 14130030 $236 30450041 $259 + $1465 33010985 (10m) $316 32990019 $99 00600002 $196
MODEL
Urano
10/12
Urano
15/21
Urano
20/15
Urano
20/21
PERFORMANCE
Water Pressure max.
1500 Psi
2175 Psi
2900 Psi
2900 Psi
Water Flow Rate
12 l/min.
21 l/min.
15 l/min.
21 l/min.
Water Temperature
30-90°C
30-90°C
30-90°C
30-90°C
Steam
Up to 140°C
Up to 140°C
Up to 140°C Up to 140°C
Coil
C2
C2
C2
C3
Hose Reel
Optional
Optional
Optional
Optional
Electric Motor:
Power Rating - Kw
2.2 kW
5.5 kW
5.5 kW
7.5 kW
Voltage
240 Volt
415 Volt
415 Volt
415 Volt
Electrical Outlet Size
15 amp
n/a
n/a
n/a
Pump/Motor Coupling
Hollow Shaft Flexible Coupling Flexible Coupling Flexible Coupling
Motor Speed - Rpm
1440 Rpm 1440 Rpm
1440 Rpm 1440 Rpm
Pump:
Pump - Type
Plunger
Plunger
Plunger
Plunger
- Head
Brass
Brass
Brass
Brass
- Interpump
W112
WS202
WS201
WS202
- Total Stop
Water Tank
Dimensions
L1000XW600XH800
LIST PRICE - Steel
$5,999
C
$6,999
C
$6,999
C
$7,999
C
LIST PRICE - SS Coil $6,799
C
$7,999
C
$8,699
C
Gun (with M22 fittings)
60031700 $120
3 Phase Plug 4Pin
165 P4P20ASP
$69
Castello Urano
Hot Water/Steam
Lance c/w Turbo Nozzle
Hour Meter $320
