Hot Water
133
KF Extra
Hot water
KF SERIES - Our heavy duty series, fitted with an industrial 1440Rpm
electric motor, Premium series Comet Italian pump and heavy duty
frame -
Proudly built by Comet in Italy
Meg Nozzle
18.15 16.1325.50 $19
9.18 16.1325.60 $19
10.21 16.1325.xx $19
INDUSTRIAL - KF SERIES
Electric Pressure Cleaners - Hot Water
KF Series
ACCESSORIES INCLUDED
HOT WATER - INDUSTRIAL “KF Extra”
Industrial use is defined as one where the machine is to be used
in an industrial application, and on a constant basis
General Fe
atures:
Pump
• Comet Premium Plunger pump (not KF3.11) with Brass Head
and ceramic pistons
Motor
• Heavy duty 4 pole electric motor (1400 rpm) with corrosion
protection.
• Double flange motor with elastic joint (not KF3.11)
• Self priming pump with “
Easy Start
” mechanism guarantees
motor will start in all conditions
• Delayed
TOTAL STOP
automatically shuts down the pressure
washer down when the gun is closed
• Motor protection with thermal relay in case of overheating
Boiler
• Double Coil boiler with stainless external boiler body
• Delayed burner start
• Flame control device system
Control Panel
• Display Lamps for “machine switched on”, “low fuel level”,
“timed shutdown”, “leak detected”, “motor thermal overload” and
“burner malfunction”
• Temperature adjustment knob
• Low voltage controls
• Remote control switch
Other
• Strong heavy duty metal frame with bumper to prevent transit
damage
• Large capacity 19 Litre diesel tank
• Built in 16 Litre detergent tank
• High pressure detergent system with regulation
• Inbuilt water tank with float to guarantee water is kept up to the
pump
• Water softener device with pump & tank
Standard Options
Hose 10m
8.15 33010776 $160
9.18 33010944 $199
10.21 tba
Options available:
Hose Reel + 15m hose
8.15 70020238 $475
9.18 70020246 $399
10.21 tba
Lance c/w Turbo Nozzle
8.15 33010893 $159
9.18 33010897 $159
10.21 tba
Steam Nozzle c/w Lance
33011100 $119
Sandblasting Lance Foam Lance Rotating Brush Drain Clng Kit 25m Stainless Coil Hose extensions Suction Hose Kit Coil Descaler (10ltr)
KF8.15 33010772 $399 33010901 $169 14130030 $236 30450041 $259 + $9010 33010985 (10m) $316 32990019 $99 00600002 $196
KF9.18 33010772 $399 33010901 $169 14130030 $236 30450036 $189 + $na 33010946 (10m) $184 32990019 $99 00600002 $196
KF20.21 33010772 $399 33010901 $169 32990019 $99 00600002 $196
MODEL
KF8.15
KF9.18
KF10.21
PERFORMANCE
Water Pressure - max.
2900 Psi
2900 Psi
3000 Psi
Water Flow Rate
15 l/min.
18 l/min.
21 l/min.
Water Temperature
0-90°C
0-90°C
0-90°C
Hose Reel
Optional
Optional
Optional
Electric Motor:
Power Rating - Kw
5.5 kW
6.6 kW
8.9 kW
Voltage
415 Volt
415 Volt
415 Volt
Electrical Outlet Size
n/a
n/a
n/a
Motor Speed - Rpm
1440 Rpm 1440 Rpm 1440 Rpm
Thermal Motor Prot.
Pump:
Pump - Type
Premium
Premium
Premium
- Head
Brass
Brass
Brass
- Pistons
3
3
3
- Total Stop
Weight
125 kg
150 kg
165 kg
Dimensions
L132XW82XH96
LIST PRICE - Steel Coil $5,499
C
$5,999
C
$6,799
C
LIST PRICE - Stainless $6,699
C
n/a
$7,716
C
3 Phase Plug 4Pin
165 P4P20ASP
$69
Gun (with M22 fittings)
24100114 $145
Lance (no nozzle)
33010974 $49
