Hot Water
2014 August: Prices exclude Freight and GST. Subject to change without notice
136
Vulcan - Super heavy duty, with twin boilers
to guarantee a constant temperature and
maximum efficiency
INDUSTRIAL - VULCAN SERIES
Electric Pressure Cleaners - Hot Water
Vulcan Twin Burner Series
MODEL
Vulcan
15/30
Vulcan
20/30
PERFORMANCE
Water Pressure - max.
2175 Psi
2900 Psi
Water Flow Rate
30 l/min.
30 l/min.
Water Temperature
30-90°C
30-90°C
Steam
Up to 140°C
Up to 140°C
Hose Reel
Optional
Optional
Electric Motor:
Power Rating - Kw
7.5 kW
11 kW
Voltage
415 Volt
415 Volt
Electrical Outlet Size
n/a
n/a
Motor Speed - Rpm
1440 Rpm
1440 Rpm
Pump:
Pump - Type
Plunger
Plunger
- Head
Brass
Brass
- Interpump
- Total Stop
Water Tank
Weight
Dimensions
L1200xW900XH1200
LIST PRICE
$11,999
$11,999
285 kg
Vulcan
20/25
2900 Psi
25 l/min.
30-90°C
Up to 140°C
Optional
9.2 kW
415 Volt
n/a
1440 Rpm
Plunger
Brass
$11,999
Castello Vulcan
Hot Water/Steam
Important owners check list:
At machine Start Up:
•
Connect water supply to machine, checking filter is clean
•
Turn water on
•
Check Pump oil, diesel fuel and detergent levels
•
Check high pressure hose for wear, leaks or damage
•
Turn machine on
•
Turn Control switch to Hot
•
Set thermostat to desired temperature
•
Operate
After use:
•
Turn thermostat to zero
•
Turn control switch to cold & turn detergent off
•
Run machine until lance is cold to touch
•
Turn machine off
•
Turn off power & water
•
Pull trigger to release any line pressure
Features:
Stainless Cover
Efficient vertical boiler 3/8” x 2
Double spiral coil
Ventilation by independent electric motor, High pres-
sure detergent suction
Interpump pump with ceramic plungers
4-pole motor (1450rpm) s1 continuous working
Bypass valve
Safety valve
Burner control with flow switch and thermostat Low
tension electric control (24v)
Low level gas oil warning lamp with burner stop Power
on lamp.
T.S.T System (Timed total switch)
D.S.S System with:
Leakage control
Stop after 1 hour of standby
Flame control with photocell
