Hot Water
125
Boilers
Boiler Options
C1
Standard Coil (10 to 13 l/min up to 2000 Psi) Part #
109
Boiler C1 List $poa
C1
Stainless Coil (10 to 13 l/min up to 2000 Psi) Part #
109
Boiler C1SS List $poa
Configuration Options
Flow
True Temp.
Dimensions
Weight Fuel Nozzle
13 l/min
30° to 80°
Diameter 32cm
Height 53cm
41kg
12 l/min
30° to 85°
11 l/min
30° to 90°
10 l/min 30° to 100°
C2
Standard Coil (12 to 21 l/min up to 3000 Psi) Part #
109
Boiler C2 List $966
C2
Stainless Coil (12 to 21 l/min up to 3000 Psi) Part #
109
Boiler C2SS List $poa
Configuration Options
Flow
True Temp.
Dimensions
Weight Fuel Nozzle
12 l/min 30° to 100°
Diameter 32cm
Height 63cm
52kg
1.35
15 l/min
30° to 80°
1.50
21 l/min
30° to 75°
1.75
C3
Stainless Coil (15 to 21 l/min up to 5000 Psi) Part #
109
Boiler C3SS List $2,699
Configuration Options
Flow
True Temp.
Dimensions
Weight Fuel Nozzle
15 l/min 30° to 100°
Diameter 32cm
Height 73cm
67kg
21 l/min
30° to 80°
67kg
2.0
C4
Standard Coil (15 to 21 l/min up to 5000 Psi) Part #
109
Boiler C4 List $2,299
Configuration Options
Flow
True Temp.
Dimensions
Weight Fuel Nozzle
15 l/min 30° to 100°
Diameter 32cm
Height 73cm
67kg
21 l/min 30° to 100°
67kg
2.0
Note: All temperatures reported in “true temperature”, not “industry standard”
Spec No.
Spec No
91020100
Spec No
change nozzle
91031100
Spec No
change nozzle
91030400
Boilers
Build your own Hot Water machine, or refurbish an existing one.
Our Boilers are the same ones supplied in our Urano & Fire machines:
Features:
Stainless Boiler Housing
Option of Standard or Stainless Water Coil
C1 & C2 Coil with 3/8” OD & 2.5mm wall thickness
C3 & C4 Seamless Coil with 3/8” OD & 2.8mm wall thickness
Full Boiler, including all cables to (but not including) the control box
Excludes tubing to feed diesel (due to numerous options)
Temperatures reported in “true temperature”, not “industry standard”
Fuel Pumps, Ignition Electrodes, Fuel Nozzles
See BURNER EQUIPMENT on Page 403 for parts
24 Volt / 240 Volt
