Hot Water
2014 August: Prices exclude Freight and GST. Subject to change without notice
116
“Hot Spot” Electric Pressure Cleaners
TECHNICAL FEATURES -
The new HOT SPOT is a professional static high pressure cleaner, with a completely STAINLESS STEEL AISI 304
cabinet. A compact machine that meets all the requirements of a professional market
Model
Pressure
Water
Delivery
Motor
Power
Absorbed
Power
Voltage
109
HOTSPOT 12/10
30 - 120 BAR
5-10 lt/m
2.2 kW
3 KW
Single Phase 230 V
109
HOT SPOT 15/15
30 - 150 BAR
5-15 lt/m
4.0 kW
5 KW
Three Phase 230-400V
109
HOT SPOT 15/21
30 - 150 BAR
5
-21 lt/m
5.5 kW
6,5 KW
Three Phase 230-400V
109
HOT SPOT 20/15
30 - 200 BAR
5-15 lt/m
5.5 kW
6,5 KW
Three Phase 230-400V
109
HOT SPOT 20/21
30 - 200 BAR
5
-21 lt/m
7.5 kW
8,5 KW
Three Phase 230-400V
Boiler
C2
C2
C3
C2
C3
List
Price
$8,259 C
$9,199 C
$9,199 C
$9,199 C
$9,999 C
TECHNICAL DESCRIPTION line HOT SPOT
• Interpump Piston Pump
• Nicolini Electrical motor 230-400V with 2 bearings, overload thermal protec-
tion and with double flange...manufactured in Italy
• STAINLESS STEEL vertical boiler with weldless double coil 3/8", bottom
made of refractory cement.
• Boiler C2 for model :120/10 – 100/10 – 150/15 – 200/15. BIG Boiler C3 for
models: 150/21 and 200/21
• Delayed start of 6 sec. of the burner spark
• Independent burner
• Flame control of the burner by photocell for the maximum safety standards
• Stainless steel water tank with automatic float level
• Machine stop in case of micro-leakages
• Device on the control panel for the suction of the detergent on high pressure
• Thermostat regulation temperature 30°-120° C
• Temperature : 30°C – 150°C
• Nr. 3 pressure switches and 1 flow switch
• Safety valve
• Automatic stop of the machine if left idle for 30 min
• Electric panel at 24 volts complete of remote control switch and thermal over-
load
• Transformer 230-400-24 Volt
• Delayed total stop adjustable 0-30 sec
• Stop of burner for lack of fuel
• Anti-shock dumper standard on the model URANO 20/21, on request for the
other models of the range
• Pressure gauge for pressure adjustment
• By pass valve
• Inlet water filter
• Water filter before the pump
• Detergent filter with no-return valve
• Fuel filter
• Supplied with 10 metres of R2 hose, 120cm lance and fan nozzle
NOTE: NO DIESEL TANK INCLUDED
Ideal where independent diesel source is available
