Hot Water
2014 August: Prices exclude Freight and GST. Subject to change without notice
114
Electric Pressure Cleaners - Urano Hot Water
NORMAL USE
PROFESSIONAL
MODEL
HYDRA
10/12
HYDRA
17/13
PERFORMANCE
Water Pressure (Operating)
1550 Psi
2500 Psi
Water Flow Rate
12 l/min.
13 l/min.
Water Temperature
30
°
C to 80
°
C
30
°
C to 80
°
C
Steam
no
no
Electric Motor:
Power Rating - Kw
2.2Kw
2.2Kw
Voltage
240 Volt
415 Volt
Motor Speed - Rpm
1440 Rpm
1440 Rpm
Motor/Pump Coupling
Hollow Shaft
Hollow Shaft
Pump:
Pump - Type
Interpump Triplex Piston Pump
Interpump Triplex Piston Pump
- Model
W112
EL1714
- Head
Brass
Brass
Water Break Tank
no
no
Burner:
Type
C2 Double Coil (3/8” seamless)
C2 Double Coil (3/8” seamless)
Coil Mounting
Vertical
Vertical
Weight
130Kgs
130Kgs
Dimensions
H825 x W540 x L930
H825 x W540 x L930
STANDARD ACCESSORIES
Gun
Lance - Ins. Grip 1200mm
Nozzles - Fan
Hose Length
10 metres
10 metres
Nozzles - Steam
n/a
n/a
Detergent Injection
Low Pressure
Low Pressure
Stainless Coil Option
Full Specification Sheet
Page 140
Page 140
Service Parts
Page 138
Page 138
LIST PRICE
$4,999
C
$4,699
C
+ Stainless Coil
HYDRA 10/12SS $5,863
Premium Italian
Quality
Hydra
The Urano series features Electronic
Card over-ride. If you are operating in
a remote area and the Card is shutting
down the machine due a fault, you can
over-ride the card.
Of course, this should only be a short
term solution before undertaking the
required repairs.
Hose Reel:
Part # 114 Mounting Bracket $148
Part # 125 85.402.001 Reel $269
Part # 165 Labour to fit $308
