CHEMICAL KIT - High Pressure
Placed on the inlet side of the pump.
Used to provide soap discharge at
pressure washers Maximum Pressure
Specifications:
Flow:
11 l/min.
Pressure:
3500 Psi
Temp:
82°C
***suitable for machines to 11l/min
***not suitable for gravity fed inlet water
Part #
Inlet Outlet
List
85.400.003 3/4” Npt F 3/4” Npt M .
$75
Foaming Equipment & Accessories
Detergent Injectors
USING “DOWNSTREAM” DETERGENT INJECTORS
Plumbing:
The detergent Injector is installed between the pump/
unloader and the high pressure outlet hose.
Remember:
►Follow the arrows when installing. “IN” affixes to
the unloader and “OUT” affixes to the high pressure
hose
►Select the appropriate injector to suit the flow of
your machine
►The injector functions only if the “out” channel is at
low pressure. ie make sure the low pressure
detergent nozzle is fitted, not a 0°, 15°, 25° or40°
► Fit a clear plastic tube between the detergent port
on the injector and your detergent bottle (make sure it
is diluted as per the instructions on the detergent
bottle)
► When finished, make sure you run the pressure
washer without dertergent to remove any residue that
may cause sticking during the next use
DETERGENT INJECTOR - STAINLESS
► Pressure to 5650Psi (max) ► Flow to 30 l/min. ►Temp to 90°C
Low Pressure Venturi - Stainless
148
541 69 3/8” Bsp M 3/8” Bsp M
148
541 70 3/8” Bsp M 3/8” Bsp M
Variable
1
.8mm $299
2.1
mm $299
