2014 August 1: Prices exclude Freight and GST. Subject to change without notice
382
DETERGENT INJECTOR - Low Pressure Venturi (High Flow)
Adjustable high draw chemical injector
draws up to 20% chemical
Specifications:
Flow:
7-30 l/min., 90°C
Pressure:
4500 Psi (max.)
Temp:
90°C
Part #
Inlet Outlet Flow
List
85.300.093 use 21.0150.18 3/8” Npt M 3/8” Npt M 7 to 11 l/min. $65
85.300.094 use 21.0150.21 3/8” Npt M 3/8” Npt M 11 to 19 l/min. $84
85.300.095 use 21.0150.23 3/8” Npt M 3/8” Npt M 19 to 30 l/min. $65
DETERGENT INJECTOR - Npt - Low Pressure Venturi
Specifications:
Flow:
7-19 l/min., 90°C
Pressure:
4000 Psi (max.)
Temp:
90°C
Part #
Inlet Outlet Flow
List
85.300.090 3/8” Npt M 3/8” Npt M 7 to 19 l/min.
$41
85.300.091 3/8” Npt M 3/8” Npt F 7 to 19 l/min.
$36
85.300.097 QC Plug QC Female 11 to 19 l/min.
$47
85.400.001 Is 85.300.097 c/w 90cm chemical hose
$51
85.300.090 85.300.097 85.400.001
Part #
Inlet Outlet
Nozzle
Flow
(l/min)
List
Fixed
145
21.0000.18 3/8” Bsp M 3/8” Bsp M 1.8mm 8 to 12 $29
145
21.0000.21 3/8” Bsp M 3/8” Bsp M 2.1mm 10 to 15 $29
145
21.0080.21
as above - 7mm hose barb can be set in different directions
$35
Variable
145
21.0170.18 3/8” Bsp F 3/8” Bsp M 1.8mm 8 to 12 $38
145
21.0175.18 3/8” Bsp M 3/8” Bsp F
1.8mm 8 to 12 $39
145
21.0180.18 3/8” Bsp M M22 AR1
1.8mm 8 to 12 $39
145
21.0150.21 3/8” Bsp M 3/8” Bsp M 2.1mm 10 to 15 $38
145
21.0130.21
as above - 7mm hose barb can be set in different directions
$48
145
21.0175.21 3/8” Bsp M 3/8” Bsp F
2.1mm 10 to 15 $38
145
21.0185.21 M22 AR1 B M22 AR1 A 2.1mm 10 to 15 $66
145
21.0175.23 3/8” Bsp M 3/8” Bsp F
2.3mm 12 to 18 $40
145
21.0175.25 3/8” Bsp M 3/8” Bsp F
2.5mm 14 to 22 $39
145
21.0175.27 3/8” Bsp M 3/8” Bsp F
2.7mm 17 to 26 $39
21.0006.51
1.2mm Sst
poa
21.0007.51
1.5mm Sst
poa
21.0002.51
1.8mm Sst
poa
Replacement Nozzles:
21.0157.51
2.3mm Sst
poa
21.0004.51
2.1mm Sst
poa
Part #
Inlet
Outlet
Nozzle Flow
(l/min)
List
Fixed
155
0203003010 3/8” Bsp F 3/8” Bsp M 1.8mm 8 to 12
$21
155
0203002010 3/8” Bsp M 3/8” Bsp M 1.8mm 8 to 12
$19
155
0203003020 3/8” Bsp F 3/8” Bsp M 2.1mm 10 to 15
$20
155
0203002020 3/8” Bsp M 3/8” Bsp M 2.1mm 10 to 15
$21
Adjustable
155
0203003110 3/8” Bsp F 3/8” Bsp M 1.8mm 8 to 12
$27
155
0203002110 3/8” Bsp M
3/8” Bsp M 1.8mm 8 to 12
$27
155
0203003120 3/8” Bsp F
3/8” Bsp M 2.1mm 10 to 15
$30
155
0203002120 3/8” Bsp M
3/8” Bsp M 2.1mm 10 to 15
$31
DETERGENT INJECTOR
► Pressure to 4060Psi (4500max) ► Flow to 30 l/min. ►Temp to 90°C
Low Pressure Venturi - Bsp Budget
Low Pressure Venturi - Bsp Premium
Fixed
Adj.
Adj.
Fixed
Foaming Equipment & Accessories
Detergent Injectors
