2014 August 1: Prices exclude Freight and GST. Subject to change without notice
364
Nipples & Couplings
TEMA Quick Connect - Valved
QC COUPLING - ARS178 & 178L
Stainless Quick Couplers designed for the food industry
Viton seals, large 12mm internal passage & 17.8mm Pin
Inlet: See below
Outlet: QC B
Flow: 50 l/min.,
Pressure: 3650 Psi (4050max.)
Temp. 90
°
C
Material: SS with Viton Seals
Inlet: See below
Outlet: QC A
Flow: 50 l/min.,
Pressure: 3650 Psi (4050max.)
Temp. 90
°
C
Material: Hardened Stainless
Inlet: See below
Outlet: QC A
Flow: 50 l/min.,
Pressure: 1825 Psi (2025max.)
Temp. 90
°
C
Material: Austempered
Stainless
145
26.2500.10 3/8”BspF $64
145
26.2520.00 1/4”BspF $21
145
26.2530.00 1/4”BspF $21
145
26.2500.30 1/2”BspF $75
145
26.2520.10 3/8”BspF $22
145
26.2530.10 3/8”BspF $21
145
26.2500.40 1/2”BspM $65
145
26.2520.30 1/2”BspF $28
145
26.2530.30 1/2”BspF $29
145
26.2520.40 1/2”BspM $28
145
26.2530.40 1/2”BspM $29
Tema Unvalved option
TEMA COUPLINGS & PLUGS - VALVED FOR HYDRAULIC FLUIDS
This Hydraulic Quick Release Self Sealing Coupling is designed for use with Hydraulic oils.
AGA Approval No 4444 (except 1/8” version)
TEMA Coupling
TEMA Plug
Dust Plug
Dust Cap
O Ring Kit
Nitrile 100°
O Ring Kit
Viton 200°
1/4” 3/8” 1/2”
Nitrile Seal
to 100°C
Nitrile Plug
to 100°C
Inlet
1/8”
165
BF2310
2900 Psi
$55
165
BF2320
2900 Psi
$24
1/4”
165
BF2510
6520 Psi
$49
165
T2520
6520 Psi
$37
165 BF2516 $5 165 BF2526 $5 165 BF2500PSN $7
165 BF2500PSV $16
3/8”
165
BF3810
5000 Psi
$85
165
T3820
5000 Psi
$35
165 BF3816 $6 165 BF3826 $6 165 BF3800PSN $7
165 BF3800PSV $11
1/2”
165
BF5010
4650 Psi
$96
165
BF5020
4650 Psi
$49
165 BF5016 $7 165 BF5026 $7 165 BF5000PSN $5
165 BF5000PSV $15
3/4”
165
BF7510
4000 Psi
$150
165
BF7520
4000 Psi
$72
165 BF7516 $8 165 BF7526 $8 165 BF7500PSN $6
165 BF7500PSV $12
1”
165
T10010
3625 Psi
$222
165
T10020
3625 Psi
$99
165 BF10016 $8 165 BF10026 $8 165 T10000PSN $9 165 BF10000PSV $19
1 1/2”
165
BF15010
2900 Psi
$699
165
BF15020
2900 Psi
$429
165 BF15016 $59 165 BF15026 $59 165 BF15000PSN $23 165 BF15000PSV $33
2”
165
BF20010
$poa
165
BF20020
$poa
165 BF20016 $poa 165 BF20026 $poa 165 BF20000PSN $poa 165 BF20000PSV $33
