361
Coupler “B” - Quick Connect for 1/2” Plug
A
QC 1/2” Coupling
B
A
QC 1/2” Coupling
B
A
QC 1/2” Coupling
B
A
QC 1/2” Coupling
B
1/2” Npt F
1/2” Npt F
1/2” Npt F
1/2” Npt M
Brass
to 3000 Psi
Stainless
to 5000 Psi
Brass
to 3000 Psi
Stainless
To 5000 Psi
125
85.300.153
125
85.300.153S
125
85.300.152
125
85.300.152S
List $33
List $39
List $23
List $42
Plug “A” - Quick Connect for 1/2” Plug
A
QC 1/2” Plug
B
A
QC 1/2” Plug
B
1/2” Npt F
1/2” Npt M
Stainless Steel
to 5000 Psi
Stainless Steel
to 5000 Psi
125
85.300.151S
125
85.300.150S
List $19
List $19
QUICK CONNECT 1/2” Npt Thread
3 O Ring - Npt to 5650 Psi
A
QC 1/2” Coupling
B
A
QC 1/2” Plug
B
3/8” Npt F
3/8” Npt F
Stainless Steel
to 5650 Psi (50l/min)
Stainless Steel
to 5650 Psi (50l/min)
125
85.300.155S
125
85.300.154S
List $27
List $10
3 O Ring - Bsp to 5650 Psi ARS350
A
QC 1/2” Coupling
B
A
QC 1/2” Plug
B
3/8” Bsp F
3/8” Bsp F
Stainless Steel
to 5650 Psi
Stainless Steel
to 5650 Psi
145
26.2050.00
145
26.2035.51
List $69
List $30
3 O Rings
Nipples & Couplings
Quick Connect Type
QUICK CONNECT - 3 O-Ring Seal
3 O Ring - Bsp to 3650 Psi ARS220
A
QC 1/2” Plug
B
A
QC 1/2” Coupling
B
3/8” Bsp F
3/8” Bsp F
Nickel Plated Steel
to 3650 Psi
Nickel Plated Steel
to 3650 Psi
145
26.2030.00
145
26.2035.61
List $41
List $15
145 26.2045.51 1/4”M $30
145 26.2050.20 1/4”F $69
145 26.2050.25 1/4”M $79
“FOOD GRADE” QC COUPLING - ARS178 & 178L
Stainless Quick Couplers designed for the food industry - Viton seals, large 12mm internal passage & 17.8mm Pin
Inlet: See below
Outlet: QC B
Flow: 50 l/min.,
Pressure: 3650 Psi (4050max.)
Temp. 90
°
C
Material: SS with Viton Seals
Inlet: See below
Outlet: QC A
Flow: 50 l/min.,
Pressure: 3650 Psi (4050max.)
Temp. 90
°
C
Material: Hardened Stainless
Inlet: See below
Outlet: QC A
Flow: 50 l/min.,
Pressure: 1825 Psi (2025max.)
Temp. 90
°
C
Material: Austempered SS
145
26.2500.10 3/8”BspF $64
145
26.2520.00 1/4”BspF $21
145
26.2530.00 1/4”BspF $21
145
26.2500.30 1/2”BspF $75
145
26.2520.10 3/8”BspF $22
145
26.2530.10 3/8”BspF $21
145
26.2500.40 1/2”BspM $65
145
26.2520.30 1/2”BspF $28
145
26.2530.30 1/2”BspF $29
145
26.2520.40 1/2”BspM $28
145
26.2530.40 1/2”BspM $29
Inlet: See below
Outlet: QC B
Flow: 50 l/min.,
Pressure: 3650 Psi (4050max.)
Temp. 90
°
C
Material: SS with Viton Seals
145
26.2555.30 1/2”BspF $81
145
26.2555.40 1/2”BspM $81
