343
Nozzles & Washing Accessories
Tank Cleaning
BARRELL CLEANING HEAD M25E
Part #
Description
List
145
25.4300.24 M21E Tank Cleaning Head - Without suction
230V with 12V step down transformer
$2,199 C
145
25.4350.24 M25E Tank Cleaning Head - With suction
230V with 12V step down transformer
$2,999 C
Suction Tube
145 tba
Tube 332mm (for barrels 730mm wide)
$poa C
145 80.0380.00
Tube 532mm (for barrels 940mm wide)
$226 D
145 80.0386.00
Tube 667mm (for barrels 1070mm wide)
$255 D
Nozzle change (2 required)
Sizes ( 020) 80.0350.51 (025) 80.0351.51 (030) 80.0352.51 (035) 80.0353.51 (040) 80.0354.51 $9
M25E - Repair Kit (Seals) 145 25.4360.24 $235 (Serial numbers above 519)
145
25.4350.25 M25E Tank Cleaning Head - With suction
24V
$2,699 C
M21E - Repair Kit (Seals) 145 25.4308.24 $235
Specifications:
Flow:
From 10 to 25 l/min.
Operating Pressure: 2000 Psi (2000 max)
Temperature 90
°
C
Cleans Barrel Diam. 730mm
Suction Tube: 332mm
Power:
see below
Nozzles: 2 X M24 0°
Inlet:
M22 AR1 A
Box includes set of 020,025,03,035 & 04 nozzles
The
M25E
tank cleaning head is ideal for cleaning all types
of drums and barrels. It washes and, at the same time,
siphons off the water used during the cleaning process.
Features complete orbital coverage of all internal surfaces
using high pressure flow and an overall lower water con-
sumption. Built in high quality stainless steel, with a small
spray turret to fit small barrel and tank openings.
Suction Tube
length
WITH SUCTION DEVICE TO BRING THE WATER BACK OUT OF THE BARRELL
Power ►
230v or 24v
Venturi sucks ►
up water from the
barrel
◄ Nozzles (2)
doing the
cleaning
◄ Water pick up
Water inlet ►
DUCT CLEANER
81.521 TYR-2 to 120°C Adjustable 2 Nozzle $499 C
81.721 TYR-3 to 120°C Adjustable 3 Nozzle $570 C
Many options available - Ideal Garbage Bin cleaner on lance or hose
