2014 August 1: Prices exclude Freight and GST. Subject to change without notice
342
TANK & UNDERBODY CLEANING HEAD - Self Propelling A42 R2
Part #
Description
Flow
List
145
25.5200.20 Tank Cleaning Head 15-20 $2699
145
25.5200.24 Tank Cleaning Head 15-25 $2699
145
25.5200.28 Tank Cleaning Head 20-30 $2699
145
25.5200.34 Tank Cleaning Head 30-40 $2699
145
25.5200.33 Tank Cleaning Head 40-50 $2699
Stainless versions:
145
25.5600.30 Tank Cleaning Head 25-35
$poa
145
25.5600.40 Tank Cleaning Head 35-45
$poa
145
25.5181.24 Kit 01
$poa
145
25.5182.24 Kit 02
$poa
Repair Kits:
Ideal for cleaning containers
with one open side
Specifications:
Flow: 15-50 l/min., 90
°
C
Pressure: 580Psi to 2300 Psi
Barrell Diam. 86mm minimum
Nozzles: 3 x 1/8” (not included)
Inlet: 1/2” Bsp F
:
Many more tank cleaning heads
available
HYDRAULIC (WATER) DRIVEN TANK CLEANER MI63
Part #
Length Flow max. Min ø Max. Nozzles
List
145
25.4600.04 915mm Unjetted
45mm
4 x M4
$5,229
145
25.4600.24 915mm 22 l/min. 45mm
4 x M4
$
abov
e
145
25.4600.00 915mm Unjetted
65mm
4 X 1/8 Npt $5,229
145
25.4500.20 915mm 22 l/min. 65mm
4 X 1/8 Npt $5,229
145
25.4603.20 363mm 22 l/min. 65mm
4 X 1/8 Npt $5,429
145
25.4600.30 915mm 30 l/min. 65mm
4 X 1/8 Npt $5,229
145
25.4600.50 915mm 54 l/min. 65mm
4 X 1/8 Npt $5,229
Stainless Versions
145
25.3650.40 650mm 45 l/min. 62mm
4 X 1/8 Npt $5,699
145
25.3650.50 650mm 45 l/min. 62mm
4 X 1/8 Npt $5,699
Repair Kit
145 25.4608.24
$299
145 25.4630.24
Spares Kit - Gears etc
$683
145 80.0005.52
Buffer, M10 Sst
$460
145 80.0014.51
Nozzle hold. pinion, z57,4x1/8”Npt F
$450
145 80.0009.85
Bushing, opn 15x19x14.8mm, 8mm PTFE
$14
145 80.0027.23
Pinion 34 Sst+Bushing opn 15mm
$330
145 80.0232.51
Geared shaft
$710
Nozzles & Nozzle Change
MI63 supplied standard with 2 nozzles and the other 2 ports plugged. 4 Ports used
for higher flow applications
Head with M4 Nozzles
Nozzle Sizes ( 025) 25.1091.51 (020) 25.1190.51 (035) 25.1093.51 (043) 25.1194.51 $poa
Head with 1/8” Nozzles
(045) 16.1363.45 1/8” Npt + Guide Vane 00.045
Must also change injector (x3):
(2mm) 145 80.0221.51 (3mm) 145 80.0222.51 (4mm) 145 80.0223.51 (5mm) 80.0224.51 $poa
Cycle Time: Cycle time of head is effected by flow, not pressure.
When changing nozzles, cycle time will not change if you keep the same flow rate
Spares Kit - Seals
145
25.4600.24 915mm 22 l/min. 45mm
4 x M4
$5,229
Selection note:
M25E series has suction recovery
MI63 has no suction as the liquid drains from the
tap below
Nozzle doing
the cleaning
◄
▲
Ideal for IBC cleaning
(Intermediate Bulk Container)
Flow: 15-50 l/min., 90
°
C
Pressure: 435Psi to 2300 Psi
Barrell Diam. 45mm minimum
Inlet: 3/4” Bsp F
Nozzles & Washing Accessories
Tank Cleaning
915mm
1195mm
