2014 August 1: Prices exclude Freight and GST. Subject to change without notice
310
TEC
TEC provides an enclosed cover and protected inlets/outlets to prevent filth & grime depositing inside the gun.
Especially designed by PA in Italy for use in Food & Sanitary industries
GUNS - RL82 & RL34
Designed for use with foamy detergents.
Wide inner passages allow foam to flow freely
Inlet:
1/2” Bsp F Swivel
Outlet:
1/2” Bsp F
Performance: 80 l/min., 1850 Psi (2000max.)
Temperature: 160
°
C
Material:
Internals in stainless. Externals in Brass or SS
145
30.2900.00 Gun - RL34 Brass with SS internals $149
145
30.2800.00 Gun - RL82 Stainless $349
148 575 49 - Reduction Nipple 1/2” to 1/4” $12
DUAL LANCE - LD9
Allows a quick change from low to high pressure, and viceversa
Inlet:
1/4” Bsp F
Outlet:
1/4” Npt F
Tube:
1/4” Ai303 Stainless
x 700mm
Performance: 40 l/min., 3650 Psi (4050max)
Temperature: 160
°
C
145
41.0050.00 Dual Lance in Ai303 Stainless $249
with
TEC
Guns & Lances
Food & Sanitary Industries
Ai303 Stainless
“Resists rusting from all atmospheric sources and is recommended
for use in connection with foodstuff, sterilizing solutions and with
organic chemicals”
Note on Operating & Max. performance
Operating performance indicates the “constant” performance the item is
rated at, while Maximum (max.) performance indicates the item can be
safely used at that that higher level, but for only short periods of time.
Our experience among suppliers and competitors is that if there is no
indication as to which of the two ratings methods is being used, then it
will probably be the Maximum
LANCE - Rounded Grip
Stainless Lance. 3 colour coded grips to distinguish nozzles or usage i.e. hot vs. cold water
R5
AL-F
AL-F Grip
Inlet:
1/4” Bsp M
Outlet:
1/4” Npt F
Tube: 1/4” Stainless
Performance: 40 l/min., 3650 Psi (4050max)
Temperature: 160
°
C (Sterilisation at 125
°
C)
Inlet:
1/4” Bsp M
Outlet:
1/4” Npt F
Tube: 1/4” Stainless
Performance: 40 l/min., 3650 Psi (4050max)
Temperature: 160
°
C
145
40.2160.00 Lance 500mm Black
$46
145
40.3500.22 Lance 500mm Grey $24
145
40.3300.22 Lance 300mm Grey $29
145
40.2160.30 Lance 500mm Red $51
145
40.3502.22 Lance 500mm Red $29
145
40.3302.22 Lance 300mm Red $29
145
40.2160.60 Lance 500mm Blue $51
145
40.3504.22 Lance 500mm Blue $29
145
40.3304.22 Lance 300mm Blue $29
145
40.2300.00 Lance 1000mm Black $55
145
40.3900.22 Lance 1000mm Grey $42
145
40.2300.30 Lance 1000mm Red $59
145
40.3902.22 Lance 1000mm Red $42
145
40.2300.60 Lance 1000mm Blue $59
145
40.3904.22 Lance 1000mm Blue $42
Inlet:
1/4” Bsp M
Outlet:
1/4” Npt F
Tube:
1/4” Ai303 Stainless
Performance: 40 l/min., 3650 Psi (4050max)
Temperature: 160
°
C
with
TEC
with
TEC
