Petrol
31
Hydrostatic Pipe Tester
APS Series
Model
Max. Pressure
Flow
(max.)
Engine
Pump
Rpm
Control
Valve
Gearbox
List
Petrol
120 APS41-GX200
568 Psi (40 Bar)
41 l/min.
Honda 6.5Hp Recoil start
550
12040457
50050216
$3,237 C
120 APS71-GX270
568 Psi (40 Bar)
71 l/min.
Honda 9.0Hp Recoil start
550
12040189
50050221
$4,073 C
120 APS121-GX390
568 Psi (40 Bar)
120 l/min.
Honda 13Hp Recoil start
550
12150084
$6,167 C
120 APS149-GX630
435 Psi (30 Bar)
149 l/min.
Honda 23Hp Electric start
550
$8,457 C
Diesel
120 APS41-KD225
568 Psi (40 Bar)
41 l/min.
Kohler 4.8Hp Electric start
550
$5,990 C
120 APS71-KD440
568 Psi (40 Bar)
71 l/min.
Kohler 10Hp Electric start
550
12040189
50050221
$7,999 C
120 APS121-KD500
435 Psi (30 Bar)
120 l/min.
Kohler 12Hp Electric start
550
$9,712 C
120 APS149-KD4252
435 Psi (30 Bar)
149 l/min.
Kohler 19Hp Electric start
550
$12,828 C
HIGH PRESSURE
Petrol
120 BAR2565G-HJJ HTS
2500 Psi (172 Bar)
11 l/min.
Honda 6.5Hp Recoil start
$3,249 C
120 BAR2565G-HEJJ HTS
2500 Psi (172 Bar)
11 l/min.
Honda 6.5Hp Electric start
$3,649 C
120 BAR3513G-HM HTS
3500 Psi (240 Bar)
15 l/min.
Honda 13Hp Recoil start
$4,649 C
120 BAR3513G-HEM HTS
3500 Psi (240 Bar)
15 l/min.
Honda 13Hp Electric start
$5,049 C
120 BAR4023G-HER HTS
4000 Psi (275 Bar)
20 l/min.
Honda 23Hp Electric start
$7,349 C
120 BAR5027G-HER HTS
5000 Psi (350 Bar)
21 l/min.
Honda 27Hp Electric start
$7,799 C
Diesel
120 BAR2048G-KE HTS
2000 Psi (140 Bar)
11 l/min.
Kohler 4.8Hp Electric start
$5,786 C
120 BAR3010G-KEM HTS
3000 Psi (200 Bar)
15 l/min.
Kohler 10Hp Electric start
$7,199 C
120 BAR4018G-KER HT
4000 Psi (275 Bar)
15 l/min.
Kohler 18Hp Electric start
$9,899 C
HIGH FLOW
Our range of hydro testers are designed for the contractor who needs a reliable, high quality pipe tester.
Supplied standard with:
Comet Italian Diaphragm or Plunger pump
Enclosed gear box
Double pressure gauge and lock off ball valve system
Your choice of frame
Inlet water filter
Applications include:
Pipeline pressure testing
Leak detection
Hydrostatic testing of pressure vessels
Optional equipment:
NATA certified pressure gauges
Electric start petrol engines
Skid Mount Units
600 Litre poly water tank on skid mount units
2000Psi to 7250Psi (140-500Bar) units built to your needs
Separate hire company specifications available.
Diesel Version
120 APS71-KD440
About the Dual Valve System
All hydrostatic pressure test units are fitted
with a dual valve system. This isolates the
pressure pump from the item under test when
the test pressure is reached.
When isolated the test piece is monitored
during the test period on the second pressure
gauge for any pressure drop, which would
indicate a leak.
Buyers Note:
These are high flow units. It is important to
consider how to feed enough water to the
machine
