Petrol
27
PWR Series
2 Options: Reclaims or Recycles Water
The PWR Series allow you to wash and reclaim your water on the jobsite. As you are washing equipment or surface cleaning, you will be able to
reclaim your wash water by using the included 20-foot water berm to stop water from flowing down a drain or away from your area.
The vacuum head will draw the water into the holding chamber where a second pump will force the water through an optional cyclone filter, and
then through an optional 10-micron bag filter, before returning it to your holding tank for reuse, or to a proper disposal area.
Petrol Pressure Cleaners - Cold Water
Water Reclaim & Filtration
Model
Number
Vacuum
Motor
Tank
Capacity
Filter Pump
Water
Berm
List
(No Filters)
List
(c/w Bag Filter)
List
(c/w Bag &
Cyclone Filter)
PWR-10-0ME1
3-stage, 1500W 55-gallons 1/3 HP, 8.0A, 240VAC, 50 Hz, 1Ø 6-in.x20-ft.
$2,999
$3,998
$5,777
OPTIONS
Part Number
Description
WX-0106
Wheel kit, two pneumatic tyres, powder coated steel frame and handle
WX-0107
Cyclone filter, filters down to 70-micron
WX-0108
Bag filter, 10-micron bag
WX-0109
Combination of above - cyclone and bag filters
List
$282 C
$1,580 C
$999 C
$2,470 C
PWR-19-0267 50
Filter Bag 50 micron
$76 C
PWR-19-0249 10
Filter Bag 10 micron
$76 C
System Includes:
- 1/3 HP Transfer pump
- Oil sock for absorbing oils
- Vacuum tank drain
- 3-stage vacuum motor
- Vacuum head (Scupper Tool)
- Cam lock fittings
- 50-foot vacuum hose
- 55-gallon capacity
- 20-foot water filled berm
Optional cyclone filter, filters down to
70-micron (WX-0107)
PWR-10-0ME1 shown with:
1) Optional wheel kit WX-0106
2) Optional bag filter WX-0
As displayed: List $3,998 C
Cyclone v Bag Filters:
Cyclonic Filters
remove particulate from water without the use of filters, using vortex separation. They save cost by not having to replace filter
bags, but are not effective in removing finer particulate.
Bag Filters
clean to a finer level, but are expensive and subject to choking when the water
being recycled is particularly dirty. Subject to budget, we recommend pre-cleaning with a Cylclone filter down to 70 micron, then using a Bag Filter
to do a second clean down to 10 micron.
