Electrical Accessories
FLOW SWITCH
FLOW SWITCH with Probe
Vertical
Use*
Horizontal
Use*
Rated
Pressure
Flow-
Delivery
Flow-
Feed
Voltage
Switch
Capacity
Max.
Current
Cable
In/Out
List
PA Version FL
28.0400.10
9 l/min
6 l/min
5100 psi 60 l/min 30 l/min. 230V
60VA
3A
1.25m
3/8” Bsp F
FL7
$poa
28.0400.38
4 l/min
3 l/min
5100 psi 60 l/min 30 l/min. 230V
60VA
3A
1.25m
3/8” Bsp F
FL7
$poa
28.0430.00
.3 l/min
n/a
5100 psi 60 l/min 30 l/min. 230V
60VA
3A
1.25m
3/8” Bsp F
FL7
$139
28.0450.00
9 l/min
n/a
7300 psi 60 l/min 30 l/min. 230V
60VA
3A
1.25m
3/8” Bsp F Stainless $poa
4090200001 4 l/min.
na
5075 psi
30 l/min. 250V
120VA
3A
1.57m
3/8” Bsp F
MV60
$91
4090200002
na
6 l/min.
5075 psi
30 l/min. 250V
120VA
3A
1.57m
3/8” Bsp F
MV60
$88
* Minimum Operating flow rate
Meccline Version MV60
Gauge
Bolt
Shutter
28.0500.10
3 l/min
3 l/min
3650 psi 30 l/min
230V
60VA
3A
1.25m
Delrin
3/8” Bsp M
FL3
$poa
28.0540.10
3 l/min
3 l/min
3650 psi 30 l/min
230V
60VA
3A
1.25m
Brass
3/8” Bsp M
FL3
$113
28.0535.00
3 l/min
3 l/min
3650 psi 30 l/min
230V
60VA
3A
1.25m
Brass 1/4” Bsp F 3/8” Bsp M
FL3
$poa
28.0530.10
3 l/min
3 l/min
3650 psi 30 l/min
230V
60VA
3A
1.25m
Delrin 1/4” Bsp F 3/8” Bsp M
FL3
$111
4090200004 4 l/min
na.
7252 psi
30 l/min. 250V
120VA
3A
1.57m
3/8” Bsp F Stainless $212
4090200000 9 l/min
6 l/min.
7252 psi
30 l/min. 250V
120VA
3A
1.57m
3/8” Bsp F
Brass
$190
200 505 500
7252Psi
30 l/min. 250V
1A
1.20m
3/8” Bsp F
$201
MV60
28.0400.10
28.0430.00
28.0450.00
28.0540.10
POWER PLUG Single phase
Part #
Inlet
List
165
439S TR
Power Plug 240V 10amp
$10
165
439S15HD
Power Plug 240V 15amp
$11
Domestic mains power supply in Australia is 240V AC, 50Hz.
Standard 3-pin earthed power outlets are rated at 10Amps. For larger
electric motors, nominally over 2.0kw, a 15amp plug and socket are
required
POWER PLUG 3 Phase
Part #
Inlet
List
165
P4P20ASP
Power Plug 4 Pin 20Amp
$31 Z
165
P4P32ASP TWM
Power Plug 4 Pin 32Amp
$84 D
165
P4P10ASP
Power Plug 4 Pin 10Amp
$31 Z
165
P4P10ASP TWM
Power Plug 4 Pin 10Amp
$73 D
POWER PLUGS
BATTERIES AND LEADS
Part #
Description
List
165 Battery ETX16
Gel Battery Local
$246
165 Battery Lead Set
800mm Red / Black
$44
165 61075
Battery Master Switch
$115
165 Battery Box 10 Inch
$41
XIS Battery
Battery Chinese
$99
