2014 August 1: Prices exclude Freight and GST. Subject to change without notice
408
Regulator Valves
CHEMICAL METERING VALVE - 90° RDY
Specifications:
Panel Fitting: 17mm (3/4”)
Flow:
10 l/min., 40°C
Pressure: 400 Psi (435 Psi max.)
Temp:
90°C
Part #
Couplings
Barb
List
145
29.0954.00 1/4” Bsp MM Black 7mm
$40
145
29.0960.00 1/4” Bsp MM Black nil
$39
CHEMICAL METERING VALVE RD3
Specifications:
Panel Fitting: 15mm (3/5”)
Flow:
10 l/min., 40°C
Pressure: 400 Psi (435 Psi max.)
Temp:
90°C
Part #
Couplings
Barb
List
145
29.0945.00 1/4” Bsp MM Blue
7mm
$47
145
29.0952.10 1/4” Bsp MM Black
nil
$35
CHEMICAL METERING VALVE RD5
Fluid quantity is adjusted through knob
rotation
Specifications:
Panel Fitting: 15mm (3/5”)
Flow:
10 l/min., 40°C
Pressure: 400 Psi (435 Psi max.)
Part #
Couplings
Barb
List
145
29.0980.00 1/4” Bsp MM Blue 7mm
$82
CHEMICAL METERING VALVE - Twin Inlet RD6
Fluid mixing regulated through knob
rotation
Specifications:
Panel Fitting: 14.5mm or 55mm
Flow:
1 l/min., 60°C
Pressure: 7.3 Psi
Part #
Couplings
Barb
List
145
29.0900.00 n/a
7mm
$31
148
200 066 500 n/a
7mm
$28
THERMO PROTECTOR VALVE VT.BP.1
Part #
Inlet
List
145
28.0600.00 1/2” Npt M
$95
145
28.0600.15 1/2” Bsp M
$95
INLET PRESSURE REDUCER
Flow:
32 l/min., 70
°C
Pressure:
290 Psi (max.)
Temp:
70°C
Inlet:
1/2” Bsp F
Outlet:
1/2” Bsp F
Part #
Description
List
28.0700.00 Inlet Reducer
$89
FLOW REGULATOR RF1
Part #
Description
List
29.0400.00 Inlet Reducer
$49
Flow:
30 l/min.
Pressure:
4050 Psi (max.)
Temp:
160°C
Inlet:
1/4” Bsp M
Outlet:
1/4” Bsp F
Throttling regulator for adjustable flow control
STEAM VALVE RV
1
Part #
l/min. Couplings
Knob List
29.0920.08
9
1/4” Bsp MM
No
$52
29.0920.12
13
1/4” Bsp MM
No
$47
29.0920.82
13
1/4” Bsp MM
Blue
$47
29.0920.15
15
1/4” Bsp MM
No
$47
29.0920.65
15
1/4” Bsp MM Black
$47
29.0920.70
20
1/4” Bsp MM Black
$52
Throttling nozzle for bypass flow control
Flow:
see table
Pressure:
4050 Psi (max.)
Temp:
80°C
CHECK VALVE
Check Valve VNRO - Brass
to 2300 Psi (max.) , 90
°C
Check Valve VNRO - Stainless
to 5800Psi (max.6500) , 80
°C
145
60.2040.00
25 1/4” Bsp FF
8
$29
145
60.2030.00
25 1/4” Bsp FF
8
$42
145
60.2050.00
40 3/8” Bsp FF
10
$37
145
60.2020.00
40 3/8” Bsp FF
10
$59
145
60.2075.00
180 3/4” Bsp FF
20
$58
145
60.2080.00
180 3/4” Bsp FF
20
$95
Flow regulating valve.
- Allows a one-way flow, preventing back flow
- Spring Loaded piston
- Rapid intervention at minimum flow (to 6 Psi)
Part# l/min. Ends Rated List Part# l/min. Ends Rated List
145
60.2065.00
80 1/2” Bsp FF
15
$38
145
60.2070.00
80 1/2” Bsp FF
15
$63
Specifications:
Hose barb:
7mm
Operating Temp:
63°C
Operating Pressure:
145 Psi
