299
Part #
Description
List
Interpump
222
ZZZ
Dual Lance 890mm
$159
222
ZZZLong Dual Lance 1890mm
$199
222
94.5130.00 Adaptor 1/8”F to 1/4”F
$10
145
41.0630.00
Dual Lance 890mm
$119
(10)
145
41.0600.00
Dual Lance SS Tube
$140
(10)
PA Option:
LANCE - DOUBLE (Interpump)
LANCE - DOUBLE LD9 (Premium)
Switch between high pressure and detergent
LANCES - DUAL LANCE
Part #
Description
List
155
3916.23 Dual Lance, Standard $129
LANCE - DOUBLE (Standard)
Length: 1019mm
Inlet: 1/4” Bsp M
Outlet: 1/4” Bsp F x 2
Tubing: 1/4” Stainless
DOUBLE LANCE - FRONT SECTION
Part #
Description
List
145
41.0698.00 Dual Lance Front Section - 250mm
$89
145
41.0390.00 Dual Lance Front Section - 500mm $101
145 41.0418.99
Nozzle Protector Kit
$11
nb: Kit designed for 1/4” tube, so will be a little sloppy, but effective
Length:
250mm
Inlet:
1/4” Bsp F
Outlet:
1/4” Bsp F X 2
Performance: 40 l/min., 3650 Psi
Temp:
160°C
Tubing:
1/8” Stainless
DOUBLE LANCE - FRONT SECTION
Part #
Description
List
145
41.0925.00 Dual Lance Front Section - 300mm $109
(10)
Length:
300mm
Inlet:
1/4” Bsp F
Outlet:
1/4” Bsp F X 2
Performance: 40 l/min., 3650 Psi
Temp:
160°C
Tubing:
1/4” Stainless
Lances
Dual
DOUBLE LANCE - FRONT SECTION Stainless LD9 Inox
Part #
Description
List
145
41.0050.00 Dual Lance Front Section - 700mm $249
(10)
Length:
700mm
Inlet:
1/4” Bsp F
Outlet:
1/4” Bsp F X 2
Performance: 40 l/min., 4050 Psi
Temp:
160°C
Tubing:
1/4” AISI 303
Food Industry Spec. / SS Valve
Part #
Description
List
41.0905.00 Spray Lance, Vented - 690mm
$119
(10)
41.0806.00 Spray Lance, Vented - 890mm
$139
(10)
41.0900.00 Spray Lance, Vented - 1090mm
$142
(10)
41.0900.01 Blue Stainless AISI303 throughout
$299
( )
41.0902.00 Spray Lance, Vented - 1600mm
$189
( 3)
125 85.240.300N Detergent Nozzle (must order)
$16
Optional cover
SPECIALITY DUAL LANCES
Ultra High Pressure page 392
Food Industry page 310
Inlet: 1/4” Bsp M
Outlet: 1/4” Bsp F x 2
Tubing: 1/8” Zinc Plated
Perf: 3000 Psi
Length:
Variuos
Inlet:
1/4” Bsp M
Outlet:
1/4” Bspt F x 2
Flow: :
40 l/min.
Pressure:
3650Psi (Max 4050)
Tube: Stainless Steel
Parts
41.0418.81 Nzl Protector $3
41.0906.24 Handle / Valve Kit
$99 10.3170.00 O Ring
$1
16.1855.00 Screw for Lance prot. $1 11.4513.05 Lance Hex
$1
41.0406.51 Shutter $151
41.0416.84 Shell
$51
nb: must use a combination of 1 detergent &
1 high pressure nozzle (See
page 330
)
nb: Turbo & Detergent
Nozzles not included
Description
List
Spray Lance, Vented - 1090mm $119
Part #
147
12.0278
LANCE - DOUBLE (For Turbo & Detegent Nozzle)
Turbo
Length:
1050mm
Inlet:
1/4” Bsp M
Outlet 1:
1/4” Bspt F (Detergent)
Outlet 2:
1/4” Bsp M (Turbo)
Performance: 40 l/min., 3650 Psi
Tubing:
Stainless Steel
Description
List
Spray Lance, Vented - 980mm
$192
Part #
148
200 054 600
LANCE - DOUBLE (Suttner)
Length:
980mm
Inlet:
1/4” Bsp M
Outlet 1:
1/4” Npt F (Detergent)
Outlet 2:
1/4” Npt F (Fan Nozzle)
Performance: 40 l/min., 4500 Psi
Tubing:
Stainless Steel
nb: Fan & Detergent
nozzles not included
